| PartZenbakia | CLAA080WK02 XN |
| Marka | CPT |
| Tamaina | 8.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1280×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | CPT |
| eredua | CLAA080WK02 XN |
| diagonalaren tamaina | 8.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1280(RGB)×720 [WXGA] 183PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 177.024(H)×99.576(V) mm |
| eskema dim. | 186.5(H)×117.22(V) ×13.1(D) mm |
| bezela eremua | 179.03(H)×101.58(V) mm |
| tratamendua | Antiglare (Haze 25%) |
| luminantzia | 600 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | HFFS, Normally Black, Transmissive |
| euskarria kolorea | 262K/16.7M 70% NTSC |
| argi iturria | WLED [5S4P] , 30K hours , W/O Driver |
| pisua | TBD |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| energia hornidura | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| ingurunea | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
