| PartZenbakia | C123VAN01.0 |
| Marka | AUO |
| Tamaina | 12.3 |
| Aplikazio | Automotive Display |
| Ebazpena | 1440×540 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | |
| Koloreak | 16.7M |
| Atzeko argia | - |
| Interfazea | RSDS |
| panel marka | AUO |
| panelaren tamaina | 12.3" |
| ebazpena | 1440(RGB)×540, 125PPI |
| bistaratzeko eremua | 291.6(W)×109.35(H) mm |
| eskema tamaina | 308.5(W)×129(H) mm |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M |
| maiztasuna | 60Hz |
| panelaren pisua | 580±58g |
| seinale interfazea | RSDS (1 Channel) FPC |
| ingurunea | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
| panel eredua | C123VAN01.0 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 294.8(W)×112.35(H) mm |
| azalera | Antiglare, Hard coating (3H) |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| erantzun denbora | - |
| lanpara mota | |
| pantaila taktila | Without |
| aplikazio | Automotive Display |
