BT140GW01 V.5

BT140GW01 V.5
BT140GW01 V.5
BT140GW01 V.5 thumb BT140GW01 V.5 thumb
Marka
Innolux
Tamaina
14.0
Aplikazio
NBPC
Ebazpena
1366×768
Konposizioa
LCM
Distira
200
CR
600:1
Koloreak
262K
Atzeko argia
WLED
Interfazea
LVDS
In Stock
1542
Zehaztapenak

PartZenbakia BT140GW01 V.5
MarkaInnolux
Tamaina14.0
AplikazioNBPC
Ebazpena1366×768
KonposizioaLCM
Distira200
CR600:1
Koloreak262K
Atzeko argiaWLED
InterfazeaLVDS
panel markaCHIMEI INNOLUX
panel ereduaBT140GW01 V.5 4 Compatible model
panel mota a-Si TFT-LCD , LCM
panelaren tamaina14.0 inch
ebazpena1366(RGB)×768 , WXGA
bistaratzeko moduaTN, Normally White, Transmissive
eremu aktiboa309.399×173.952 mm
eskema323.5×192×5.2 mm
forma estiloaWedge (PCBA Bent, Depth ≥5.2mm)
azaleraGlare (Haze 0%), Hard coating (3H)
distira200 cd/m² (Typ.)
kontraste-erlazioa600:1 (Typ.)
bistaratzeko koloreak262K (6-bit), CIE193145%
erantzun denbora8 (Typ.)(Tr+Td)
ikuspegi angelua40/40/15/30 (Min.)(CR≥10)(L/R/U/D)
maiztasuna60Hz
lanpara motaWLEDEmbedded (LED Driver)
seinale interfazeaLVDS (1 ch, 6-bit), 40 pins
sarrerako tentsioa3.3V (Typ.)
aplikazioNBPC
Familia Eredua
B140XTN03.1 AUO 14.0 1366×768
BT140GW01 V.0 Innolux 14.0 1366×768
BT140GW01 V.4 Innolux 14.0 1366×768
BT140GW01 V.5 Innolux 14.0 1366×768
BT140GW01 V.A Innolux 14.0 1366×768
BT140GW02 V.0 Innolux 14.0 1366×768
BT140GW02 V.2 Innolux 14.0 1366×768
BT140GW02 V.9 Innolux 14.0 1366×768
BT140GW03 V.2 Innolux 14.0 1366×768
LP140WF1-SPB1 LG Display 14.0 1920×1080
