| PartZenbakia | B156XTT01.2 |
| Marka | AUO |
| Tamaina | 15.6 |
| Aplikazio | Laptop |
| Ebazpena | 1366×768 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| fabrikatzailea | AUO |
| pantailaren tamaina | 15.6 inch |
| pixel-zenbakia | 1366(RGB)×768 (WXGA) 100PPI |
| eremu aktiboa (mm) | 344.232 × 193.536 (H×V) |
| bezela eremua (mm) | - |
| luminantzia | 200 cd/m² (Typ.) |
| ikuspegi angelua | 45/45/15/35 (Typ.)(CR≥10) |
| ikuspegi ona | 6 o'clock |
| kolore-sakonera | 262K 45% NTSC |
| eskema forma | Slim (PCBA Flat, T≤3.2mm) |
| freskatze tasa | 60Hz |
| seinale mota | LVDS (1 ch, 6-bit) , 40 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ereduaren izena | B156XTT01.2 (AUO12EC) |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 364.9 × 224.56 × 5.2 (H×V×D) |
| tratamendua | Glare (Haze 0%), Hard coating (7H) |
| kontraste-erlazioa | 500 : 1 (Typ.) (TM) |
| erantzuna | 8 (Typ.)(G to G) ms |
| lan egiteko modua | TN, Normally White, Transmissive |
| atzeko argia | WLED , 15K hours , With LED Driver |
| erabiltzen | Laptop |
| pantaila taktila | PCAP, Optical Bonding |
