| PartZenbakia | B116XAB01.3 |
| Marka | AUO |
| Tamaina | 11.6 |
| Aplikazio | Laptop |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD, Assemb |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | eDP |
| marka | AUO |
| eredua | B116XAB01.3 (AUO288C) |
| diagonalaren tamaina | 11.6 inch |
| mota | a-Si TFT-LCD, Assembly |
| pixel formatua | 1366(RGB)×768 [WXGA] 135PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 256.125(H)×144(V) mm |
| eskema dim. | 284.85(H)×189.84(V) ×4.2(D) mm |
| bezela eremua | - |
| tratamendua | Glare (Haze 0%), Hard coating (7H) |
| luminantzia | 220 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 27 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | - |
| euskarria kolorea | 16.7M 50% NTSC |
| argi iturria | WLED , 15K hours , With LED Driver |
| forma estiloa | - |
| entzat diseinatua | Laptop |
| fotograma-tasa | 60Hz |
| ukipen-panela | On-Cell Touch |
| interfaze mota | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
