| PartZenbakia | AM480272H3TMQW-TW1H |
| Marka | AMPIRE |
| Tamaina | 4.3 |
| Aplikazio | Industrial |
| Ebazpena | 480×272 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 250:1 |
| Koloreak | 65K/262K |
| Atzeko argia | WLED |
| Interfazea | 8/9/16/18-bit |
| marka | AMPIRE |
| eredua | AM480272H3TMQW-TW1H |
| diagonalaren tamaina | 4.3 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 480(RGB)×272 [WQVGA] 128PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 95.04(H)×53.856(V) mm |
| eskema dim. | 105.5(H)×67.2(V) ×7.91(D) mm |
| luminantzia | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 250:1 (Typ.) (TM) |
| ikusi norabidea | 6 o'clock |
| erantzun denbora | 15/35 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/35/55 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 65K/262K 52% NTSC |
| argi iturria | WLED [7S1P] , 15K hours , W/O Driver |
| pisua | TBD |
| entzat diseinatua | Industrial |
| fotograma-tasa | 60Hz |
| ukipen-panela | 4-wire Resistive Touch |
| interfaze mota | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
