| PartZenbakia | AM-800480L6TZQW-TN0H-I |
| Marka | AMPIRE |
| Tamaina | 5.0 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 250:1 |
| Koloreak | 16.7M |
| Atzeko argia | 3S4P |
| Interfazea | Parallel |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-800480L6TZQW-TN0H-I |
| pantailaren tamaina | 5.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 188PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 108 × 64.8 (H×V) |
| eskema (mm) | 118.5 × 77.1 × 6.44 (H×V×D) |
| bezela eremua (mm) | 110.6 × 67.4 (H×V) |
| tratamendua | - |
| luminantzia | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 250 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 15/35 (Typ.)(Tr/Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | Normally Black, Transmissive |
| kolore-sakonera | 16.7M 52% NTSC |
| atzeko argia | 3S4P WLED , 30K hours , No Driver |
| masa | - |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | PCAP |
| seinale mota | Parallel RGB (1 ch, 8-bit) , FPC 45 pins |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
