| PartZenbakia | AM-640480G4TNQW-TA0H |
| Marka | AMPIRE |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 640×480 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 250:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-640480G4TNQW-TA0H |
| pantailaren tamaina | 5.7 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 640(RGB)×480 (VGA) 141PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 115.2 × 86.4 (H×V) |
| eskema (mm) | 127 × 98.43 × 9.1 (H×V×D) |
| bezela eremua (mm) | 118.0 × 89.2 (H×V) |
| tratamendua | - |
| luminantzia | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 250 : 1 (Typ.) (TM) |
| ikuspegi angelua | 70/70/50/50 (Typ.)(CR≥10) |
| erantzuna | 50 (Typ.)(Tr+Td) ms |
| ikuspegi ona | 12 o'clock |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 262K 50% NTSC |
| atzeko argia | WLED , 20K hours , With LED Driver |
| masa | - |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | 4-wire Resistive Touch |
| seinale mota | LVDS (1 ch, 6-bit) , Connector 20 pins |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| KG057QV1CA-G020W | Kyocera | 5.7 | 320×240 |
| PD057VU7 | E Ink | 5.7 | 320×240 |
