| PartZenbakia | AM-1024768R3TNQW-T00H |
| Marka | AMPIRE |
| Tamaina | 12.1 |
| Aplikazio | Industrial |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | |
| marka | AMPIRE |
| eredua | AM-1024768R3TNQW-T00H |
| diagonalaren tamaina | 12.1 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×768 [XGA] 105PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 245.76(H)×184.32(V) mm |
| eskema dim. | 279(H)×209(V) ×11.2(D) mm |
| luminantzia | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | - |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 262K/16.7M |
| argi iturria | WLED , 30K hours , With LED Driver |
| pisua | - |
| entzat diseinatua | Industrial |
| fotograma-tasa | 60Hz |
| ukipen-panela | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| B121EW02 V0 | AUO | 12.1 | 1280×800 |
| G121X1-L01 | Innolux | 12.1 | 1024×768 |
| HV121WX5-121 | HYDIS | 12.1 | 1280×800 |
| LP121X05-A2 | LG Display | 12.1 | 1024×768 |
| LTD121KX4K | TOSHIBA | 12.1 | 1280×800 |
| NL8060BC31-47D | NLT | 12.1 | 800×600 |
| TX31D32VM2AAA | KOE | 12.1 | 800×600 |
