| PartZenbakia | AM-1024768R2TNQW-T00H |
| Marka | AMPIRE |
| Tamaina | 12.1 |
| Aplikazio | Industrial |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 10S5P |
| Interfazea | LVDS |
| panel marka | AMPIRE |
| panelaren tamaina | 12.1" |
| ebazpena | 1024(RGB)×768, XGA, 105PPI |
| bistaratzeko eremua | 245.76(W)×184.32(H) mm |
| eskema tamaina | 279(W)×209(H) ×11.2(D) mm |
| distira | 850 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegirik onena | - |
| bistaratzeko koloreak | 262K/16.7M |
| maiztasuna | 60Hz |
| panelaren pisua | - |
| seinale interfazea | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel eredua | AM-1024768R2TNQW-T00H |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | - |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| lanpara mota | 10S5P WLED , 50K hours , Without Driver |
| pantaila taktila | PCAP |
| aplikazio | Industrial |
