| PartZenbakia | AM-1024768FCTMQW-T00H |
| Marka | AMPIRE |
| Tamaina | 10.4 |
| Aplikazio | Industrial |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1200:1 |
| Koloreak | 262K/16.2M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | AMPIRE |
| eredua | AM-1024768FCTMQW-T00H |
| diagonalaren tamaina | 10.4 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×768 [XGA] 123PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 210.4(H)×157.8(V) mm |
| eskema dim. | 238.6(H)×175.8(V) mm |
| luminantzia | 280 cd/m² (Typ.) |
| kontraste-erlazioa | 1200:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 14/11 (Typ.)(Tr/Td) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10) |
| funtzionamendu modua | Normally Black, Transmissive |
| euskarria kolorea | 262K/16.2M 57% NTSC |
| argi iturria | WLED , 30K hours , With LED Driver |
| pisua | - |
| entzat diseinatua | Industrial |
| fotograma-tasa | 60Hz |
| ukipen-panela | PCAP |
| interfaze mota | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| A104SN03 V0 | AUO | 10.4 | 800×600 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
| G104VN01 V1 | AUO | 10.4 | 640×480 |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| LT104AC36000 | TOSHIBA | 10.4 | 1024×768 |
| NL8060AC26-04 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
