| PartZenbakia | A080SN01 V0 |
| Marka | AUO |
| Tamaina | 8.0 |
| Aplikazio | DPF |
| Ebazpena | 800×600 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 400:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | AUO |
| panel eredua | A080SN01 V0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.0 inch |
| ebazpena | 800(RGB)×600 , SVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 162×121.5 mm |
| eskema | 183×141 mm |
| azalera | Antiglare |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Dithering) |
| erantzun denbora | 4/16 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 3S8PWLEDWithout Driver |
| seinale interfazea | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| sarrerako tentsioa | 3.3/11.6/15/-6.75V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikazio | DPF |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| A080SN01 V8 | AUO | 8.0 | 800×600 |
| A080SN02 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V2 | AUO | 8.0 | 800×600 |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| PD080SL3 | E Ink | 8.0 | 800×600 |
| PW080XU4 | E Ink | 8.0 | 480×220 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A070SN01 V3 | AUO | 7.0 | 800×600 |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| AT102TN03 V.1 | Innolux | 10.2 | 800×480 |
| CLAA070MA21BW | CPT | 7.0 | 800×600 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| LQ070Y3DG04 | SHARP | 7.0 | 800×480 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
